Rear Tail Light,Rear Fender Subassembly
16. Rear Tail Light,Rear Fender Subassembly
|
No. |
Model Nr |
Part Name |
Qty |
|
1 |
50T20-RLRF-001 |
Rear taillight subassembly |
2 |
|
2 |
50T20-RLRF-002 |
Right rear turning light |
1 |
|
3 |
50T20-RLRF-003 |
Left rear turning light |
1 |
|
4 |
50T20-RLRF-004 |
Rear glisten plate |
1 |
|
5 |
50T20-RLRF-005 |
Washer |
2 |
|
6 |
50T20-RLRF-006 |
Screw |
2 |
|
7 |
50T20-RLRF-007 |
Washer hex-bolt |
2 |
|
8 |
50T20-RLRF-008 |
Flange hex-bolt |
6 |
|
9 |
50T20-RLRF-009 |
Rear fender |
1 |
