Luggage Box Subassembly
18. Luggage Box Subassembly
|
No. |
Model Nr |
Part Name |
Qty |
|
1 |
50T20-LBS-001 |
Luggage box |
1 |
|
2 |
50T20-LBS-002 |
Luggage box cover |
1 |
|
3 |
50T20-LBS-003 |
Lock spring |
1 |
|
4 |
50T20-LBS-004 |
Luggage box lock |
1 |
|
5 |
50T20-LBS-005 |
Luggage box cover rocker |
2 |
|
6 |
50T20-LBS-006 |
Washer bolt |
1 |
|
7 |
50T20-LBS-007 |
Screw |
4 |
