22. Fuel Tank Subassembly

No.	Model Nr	Part Name	Qty
1	50T20-FUTA-001	Fuel tank	1
2	50T20-FUTA-001	Pipe vaccum	1
3	50T20-FUTA-001	TubeA?B?C?D	1
4	50T20-FUTA-001	Discharge fuel position	1
5	50T20-FUTA-001	Fuel lock	1
6	50T20-FUTA-001	Fuel tank cover	1
7	50T20-FUTA-001	Sensor	1
8	50T20-FUTA-001	Piston ring	1
9	50T20-FUTA-001	Sensor pressure board	1
10	50T20-FUTA-001	Flange hex-bolt	3
11	50T20-FUTA-001	Flange hex-nut	2
12	50T20-FUTA-001	Filter net	1
13	50T20-FUTA-001	Spring	7
14	50T20-FUTA-001	Steel wire spring	3
15	50T20-FUTA-001	Fule filter	1
16	50T20-FUTA-001	The key	1
17	50T20-FUTA-001	Oil Bottle
