Luggage Box Subassembly
27. Luggage Box Subassembly
|
No. |
Model Nr |
Part Name |
Qty |
|
1 |
50T20-LUBO-001 |
Luggage box |
1 |
|
2 |
50T20-LUBO-002 |
Luggage box inner cover |
1 |
|
3 |
50T20-LUBO-003 |
Front small cover,Luggage box |
1 |
|
4 |
50T20-LUBO-004 |
Front cover,Luggage box |
1 |
|
5 |
50T20-LUBO-005 |
Screw |
2 |
|
6 |
50T20-LUBO-006 |
Flange hex-bolt |
2 |
|
7 |
50T20-LUBO-007 |
Crossing hex-bolt |
1 |
|
8 |
50T20-LUBO-008 |
Spring nut |
1 |
|
9 |
50T20-LUBO-009 |
Spring nut |
1 |
|
10 |
50T20-LUBO-010 |
Flange hex-nut |
2 |
