FRAME
23. FRAME
|
NO. |
Model Nr |
Part Name |
QTY |
|
1 |
125T-01-FRAM-01 |
FRAME |
1 |
|
2 |
125T-01-FRAM-02 |
BRACKET, FUEL TANK |
1 |
|
3 |
125T-01-FRAM-03 |
BRACKET |
1 |
|
4 |
125T-01-FRAM-04 |
BOTTOM PLATE, FUEL TANK |
1 |
|
5 |
125T-01-FRAM-05 |
HANGER, ENGINE |
1 |
|
6 |
125T-01-FRAM-06 |
CONNECTING PLATE |
1 |
|
7 |
125T-01-FRAM-07 |
FIXING PLATE |
1 |
|
8 |
125T-01-FRAM-08 |
RUBBER CUSHION |
2 |
|
9 |
125T-01-FRAM-09 |
BOLT 8?8 |
4 |
|
10 |
125T-01-FRAM-10 |
BOLT 12?.25?10 |
2 |
|
11 |
125T-01-FRAM-11 |
BOLT 6?2 |
4 |
|
12 |
125T-01-FRAM-12 |
BOLT 8?0 |
1 |
|
13 |
125T-01-FRAM-13 |
BOLT 8?0 |
1 |
|
14 |
125T-01-FRAM-14 |
BOLT 8?0 |
1 |
|
15 |
125T-01-FRAM-15 |
BOLT 8?.25?5 |
1 |
