Side Body Plastics Subassembly
08. Side Body Plastics Subassembly
|
No |
Model Nr |
Part Name |
QTY |
|
01 |
150T01-SBPS-001 |
COVER, side left |
1 |
|
02 |
150T01-SBPS-002 |
COVER, side right |
1 |
|
03 |
150T01-SBPS-003 |
TAPPING SCREW |
4 |
|
04 |
150T01-SBPS-004 |
NUT CLIP |
2 |
|
05 |
150T01-SBPS-005 |
NUT CLIP |
3 |
|
06 |
150T01-SBPS-006 |
TAPPING SCREW |
1 |
|
07 |
150T01-SBPS-007 |
TAPPING SCREW |
4 |
|
08 |
150T01-SBPS-008 |
COVER?, center |
1 |
|
09 |
150T01-SBPS-009 |
COVER?. center |
1 |
|
10 |
150T01-SBPS-010 |
COVER left |
1 |
|
11 |
150T01-SBPS-011 |
COVER right |
1 |
|
12 |
150T01-SBPS-012 |
COVER. rear? |
1 |
|
13 |
150T01-SBPS-013 |
COVER. rear? |
1 |
|
14 |
150T01-SBPS-014 |
COVER,side lower left |
1 |
|
15 |
150T01-SBPS-015 |
COVER,side lower right |
1 |
|
16 |
150T01-SBPS-016 |
TAPPING SCREW |
6 |
|
17 |
150T01-SBPS-017 |
WASHER |
6 |
|
18 |
150T01-SBPS-018 |
TAPPING SCREW |
7 |
|
19 |
150T01-SBPS-019 |
BOLT FLANGE |
2 |
