Handlebar Assy Subassembly
16. Handlebar Assy Subassembly
|
No |
Model Nr |
Part Name |
QTY |
|
01 |
150T01-HASU-01 |
HANDLEBAR ASSY |
1 |
|
02 |
150T01-HASU-02 |
CASE ASSY, throttle |
1 |
|
03 |
150T01-HASU-03 |
CRIP, throttle right |
1 |
|
04 |
150T01-HASU-04 |
CABLE ASSY, throttle |
1 |
|
05 |
150T01-HASU-05 |
CABLE ASSY, rear brake |
1 |
|
06 |
150T01-HASU-06 |
SPRING |
1 |
|
07 |
150T01-HASU-07 |
PIN |
1 |
|
08 |
150T01-HASU-08 |
NUT FLANGE |
1 |
|
09 |
150T01-HASU-09 |
LEVER,left brake |
1 |
|
10 |
150T01-HASU-10 |
SEAT,left brake |
1 |
|
11 |
150T01-HASU-11 |
ASSEMBLY SCREW |
1 |
|
12 |
150T01-HASU-12 |
SWITCH ASSY,left brake |
1 |
|
13 |
150T01-HASU-13 |
FIXED PLATE,left brake seat |
1 |
|
14 |
150T01-HASU-14 |
GRIP, left handlebar |
1 |
|
15 |
150T01-HASU-15 |
BOLT FLANGE |
1 |
|
16 |
150T01-HASU-16 |
SPACER |
1 |
|
17 |
150T01-HASU-17 |
NUT FLANGE |
1 |
|
18 |
150T01-HASU-18 |
SCREW |
1 |
|
19 |
150T01-HASU-19 |
U FLANGE NUT |
1 |
|
20 |
150T01-HASU-20 |
BOLT FLANGE |
1 |
|
21 |
150T01-HASU-21 |
INNER TUBE |
1 |
