Parts Catalogue 22
22. Parts Catalogue 22
|
No |
Model Nr |
Part Name |
QTY |
|
01 |
150T01-CA22-01 |
FRONT LUGGAGE |
1 |
|
02 |
150T01-CA22-02 |
NUT,FLANGE CAP |
1 |
|
05 |
150T01-CA22-05 |
LID,INNER BOX |
1 |
|
06 |
150T01-CA22-06 |
LOCK ASSY,INNER BOX |
1 |
|
07 |
150T01-CA22-07 |
CIRCLIP |
1 |
|
08 |
150T01-CA22-08 |
HOOK,helmet |
1 |
|
09 |
150T01-CA22-09 |
BOLT |
2 |
|
10 |
150T01-CA22-10 |
NUT |
2 |
|
11 |
150T01-CA22-11 |
COVER |
1 |
|
12 |
150T01-CA22-12 |
SCREW |
10 |
