Parts Catalogue 27
27. Parts Catalogue 27
|
No |
Model Nr |
Part Name |
QTY |
|
01 |
150T01-CA27-01 |
LIGHT ASSY, RR COMBINATION |
1 |
|
02 |
150T01-CA27-02 |
LENS, rear lamp |
1 |
|
03 |
150T01-CA27-03 |
LEN,left turn signal |
1 |
|
04 |
150T01-CA27-04 |
LEN,right turn signal |
1 |
|
05 |
150T01-CA27-05 |
LEN,license lamp |
1 |
|
06 |
150T01-CA27-06 |
WIRE |
1 |
|
07 |
150T01-CA27-07 |
BULB, stop, STANLEY |
1 |
|
08 |
150T01-CA27-08 |
BULB, WINKER |
2 |
|
09 |
150T01-CA27-09 |
BULB |
1 |
|
10 |
150T01-CA27-10 |
NUT CLIP |
4 |
|
11 |
150T01-CA27-11 |
REFLECTOR REFLEX |
1 |
|
12 |
150T01-CA27-12 |
FLANGE NUT |
1 |
|
13 |
150T01-CA27-13 |
BOLT FLANGE |
2 |
|
14 |
150T01-CA27-14 |
TAPPING SCREW |
2 |
|
15 |
150T01-CA27-15 |
TAPPING SCREW |
2 |
|
16 |
150T01-CA27-16 |
TAPPING SCREW |
2 |
|
17 |
150T01-CA27-17 |
WASHER |
1 |
|
18 |
150T01-CA27-18 |
BOLT FLANGE |
2 |
