Parts Catalogue 29
29. Parts Catalogue 29
|
No |
Model Nr |
Part Name |
QTY |
|
01 |
150T01- CA29-01 |
CDI UNIT |
1 |
|
02 |
150T01- CA29-02 |
BAND, CDI |
1 |
|
03 |
150T01- CA29-03 |
BATTERY ASSY |
1 |
|
04 |
150T01- CA29-04 |
COIL ASSY, IGNITION |
1 |
|
05 |
150T01- CA29-05 |
STARTER RELAY |
1 |
|
06 |
150T01- CA29-06 |
MAIN SWITCH |
1 |
|
07 |
150T01- CA29-07 |
HORN COMP (HIGH) |
1 |
|
08 |
150T01- CA29-08 |
FLANGE NUT |
1 |
|
09 |
150T01- CA29-09 |
RESISTOR |
1 |
|
10 |
150T01- CA29-10 |
BOLT FLANGE |
1 |
|
11 |
150T01- CA29-11 |
FLANGE NUT |
1 |
|
12 |
150T01- CA29-12 |
RECTIFIER COMP, REGULATE |
1 |
|
13 |
150T01- CA29-13 |
FLASHING RELAY AND BUZZER ASSY, turn signal |
1 |
|
14 |
150T01- CA29-14 |
HARNESS, wiring |
1 |
|
15 |
150T01- CA29-15 |
CLAMP |
3 |
|
16 |
150T01- CA29-16 |
CLAMP |
7 |
|
17 |
150T01- CA29-17 |
WIRING |
1 |
|
18 |
150T01- CA29-18 |
BOLT FLANGE |
3 |
|
19 |
150T01- CA29-19 |
BOLT HEX |
1 |
|
20 |
150T01- CA29-20 |
DUST SEAL, CAP NOLSE SUPPRESSOR |
1 |
